| Manufacturer: | MMD-MONITORS & DISPLAYS |
| Manufacturer Part No: | 10BDL5051T/00 |
| General |
| Product Type: | LED-backlit LCD flat panel display |
| Power Consumption (Max): | 18 Watt |
| Power Consumption Operational: | 4 Watt |
| Diagonal Class: | 10" |
| Diagonal Size: | 10.1" |
| Commercial Use: | Yes - interactive digital signage |
| Combined With: | Touchscreen (multi touch) / camera |
| Platform: | Android |
| Operating System: | Android OS 13 |
| TV Tuner: | No tuner |
| TV Tuner Presence: | No |
| Sensors: | G-sensor |
| PC Interface: | USB-C |
| Modes: | Portrait mode, landscape mode |
| Picture Enhancements: | Low Bright, Advanced Colour Control |
| Protection: | Tempered glass protection |
| Dimensions: | Without stand |
| Width: | 26.2 cm |
| Depth: | 2.475 cm |
| Height: | 16.4 cm |
| Weight: | 0.8 kg |
| Display |
| Colour Support: | 16700000 colours |
| Resolution: | 1280 x 800 |
| Display Format: | 720p |
| Image Aspect Ratio: | 16:10 |
| LCD Backlight Technology: | LED backlight |
| Image Contrast Ratio: | 1000:1 |
| Brightness: | 350 cd/m² |
| Viewing Angle: | 160 degrees |
| Viewing Angle (Vertical): | 160 degrees |
| Touchpoints Qty: | 10 |
| Response Time: | 35 ms |
| Display Menu Language: | Multilingual |
| Commercial Features: | PPDS Wave ready, keyboard lock |
| Operation Hours / Days: | 24 / 7 |
| Features: | Security lock slot (cable lock sold separately), Smart Power |
| Stands & Mounts |
| Flat Panel Mount Interface: | 75 x 75 mm |
| VESA Compatibility: | Yes |
| Media Player |
| Supported Memory Cards: | microSD |
| USB Port: | Yes |
| USB Ports Qty: | 2 |
| Configuration: | Rockchip RK3568 - 2 GB DDR4 - 16GB eMMC |
| Audio System |
| Speaker System: | 2 speakers |
| Output Power / Total: | 3 Watt |
| Speakers: | 2 x speaker - 1.5 Watt |
| Network & Internet Multimedia |
| Connectivity: | Wi-Fi, LAN, Bluetooth, NFC |
| LAN Protocol: | Ethernet |
| Wi-Fi Protocol: | 802.11a, 802.11ac, 802.11b, 802.11g, 802.11n |
| Bluetooth Version: | Bluetooth 5.0 |
| Connections |
| Connector Type: | HDMI output
USB 2.0
USB
LAN |
| Miscellaneous |
| Security Slot Type: | Kensington security slot |
| Cables Included: | USB cable
HDMI cable |
| Compliant Standards: | CB, RoHS, FCC Class A certified, ETL |
| Power |
| Power Device: | Power adapter |
| Power Over Ethernet (PoE) Support: | Yes |
| Power Consumption Stand by: | 0.5 Watt |
| Features: | Smart power, PoE+ support |
| Manufacturer Warranty |
| Service & Support: | Limited warranty - 3 years |
| Environmental Parameters |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
