| Main Board Desktop - Processor |
| Chipset: | Intel Z890 |
| Supports Central Processor Unit: | Intel Core Ultra Processors (Series 2) |
| CPU Socket Standard: | Socket 1851 |
| CPU Maximum Quantity Supports: | 1 |
| Main Board Desktop - Memory |
| Memory Type: | DDR5 SDRAM |
| Memory Form Factor: | DIMM 288-pin |
| Memory Speed: | 9200 MT/s |
| Maximum Installable System Memory Storage Capacity: | 256 GB |
| Memory Slot Total Quantity: | 4 |
| Provides Error Checking Method: | non-ECC |
| Memory Features: | Two DDR Channels
Unbuffered
XMP 3.0 |
| Controller |
| Integrated: | Storage Controller:
Supports: Level 0, Level 1, Level 10, Level 5
SATA III-600 (4)
Storage Controller:
Supports: Level 0, Level 1, Level 10, Level 5
PCI Express 4.0 x4 (3 x M.2)
Storage Controller:
Supports: Level 0, Level 1, Level 10, Level 5
PCI Express 5.0 x4 (1 x M.2)
|
| Main Board Desktop - Audio Output |
| Audio Integrated: | yes |
| Audio Chipset: | Realtek ALC897 |
| Audio Output Mode: | 7.1 Channel Surround |
| Compliant Audio Standards: | High Definition Audio
Audio Boost |
| Main Board Desktop - Networking Specifications |
| LAN Integrated: | yes |
| LAN Chipset: | Realtek RTL8126 |
| WLAN: | M.2 |
| Wi-Fi: | IEEE 802.11ax Wi-Fi 6E |
| Bluetooth: | Bluetooth 5.3 |
| Data Link Protocol Supports: | 5 Gbps |
| Slot Provided |
| PCI Express 5.0 x16: | 1 |
| PCI Express 4.0 x4: | 2 |
| PCI Express 4.0 x1: | 1 |
| Interface Provided |
| PS/2: | 1 (6-pin) |
| LAN: | 1 (RJ-45) |
| Audio Interface: | 3 (3.5-mm minijack) |
| HDMI 2.1: | 1 (HDMI (Type A)) |
| DisplayPort: | 1 |
| Wi-Fi Antenna: | 2 |
| USB 3.2 Gen 2: | 1 (USB Type C); 1 (USB Type-A) |
| USB 3.2 Gen 1: | 2 (USB Type-A) |
| USB 2.0: | 4 (USB Type-A) |
| Main Board Desktop - Mainboard Features |
| BIOS Features: | MSI CLICK BIOS X |
| Hardware Monitoring: | Diagnostic LEDs |
| Power Connectors Type: | 24 pin |
| Mainboard Features: | RGB Mystic Light
Overcurrent Protection (OCP) |
| Main Board Desktop - Software |
| Supported Operating System: | Microsoft Windows 11 64-bit |
| Miscellaneous |
| Cable Included: | 2 x SATA cables
1 to 2 EZ Conn-Cable (V1) |
| Built-in Devices: | BIOS FlashBack Button |
| Included Accessories: | Documentation
WiFi antenna
M.2 Screw/Standoff Set |
| Main Board Desktop - Dimensions&Weight |
| Form Factor: | ATX |
| Height (mm): | 304.8 mm |
| Width (mm): | 243.84 mm |
| Warranty |
| Warranty Products Returnable: | Yes |
| Warranty Term (month): | 36 month(s) |
| Warranty Validation Criteria: | Serial Number |
| Logistic |
| Pack Length (mm): | 268 mm |
| Pack Width (mm): | 70 mm |
| Pack Height (mm): | 342 mm |
| Pack Weight Brutto (kg): | 1.7 kg |
| Pack Weight Netto (kg): | 1.13 kg |
| Pieces in pack: | 1 |
| Box Weight Brutto (kg): | 1.7 kg |
| Packs in Box: | 1 |
| Package Type: | Box |
| EAN Code: | 4711377429627 |
