Парт.№: 90MB1KR0-M0EAY0
Кат.№: 146827
Кат.№: 146827
Цена с ДДС:
1731 лв.
Цена с ДДС:
885.05 €
изчерпан
| Подд. процесори: | AMD Socket AM5 for AMD Ryzen™ 9000&8000&7000 Series Desktop Processors |
| Чипсет: | AMD X870E |
| Памет/тип/: | 2 x DIMM slots, max. 128GB, DDR5, Supports up to, 8200+MT/s(OC) with Ryzen™ 9000 Series Processors,, 9600+MT/s(OC) with Ryzen™ 8000 Series Processors, 8000+MT/s(OC) with Ryzen™ 7000 Series Processors,, ECC and Non-ECC, Un-buffered Memory*, Dual channel memory architecture, Supports AMD Extended Profiles for Overclocking (EXPO™), ASUS Enhanced Memory Profile (AEMP) |
| Разш. слотове: | AMD Ryzen™ 9000&7000 Series Desktop Processors*, 2 x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8** or x8/x4/x4 modes***), ** When you use both PCIEX16 1 and PCIEX16 2, PCIEX16 1 and PCIEX16 2 will run x8., ***When M.2 3 are enabled, PCIEX16 1 will run x8, and PCIEX16 2 will run x4., **** When M.2 2 and M.2 3 are enabled simultaneously, PCIEX16 2 will be disabled., AMD Ryzen™ 8700&8600&8400 Series Desktop Processors*, 2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16 1&total bandwidth for x8, PCIEx16 2 will be disabled), AMD Ryzen™ 8500&8300 Series Desktop Processors*, 2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16 1&total bandwidth for x4, PCIEx16 2 will be disabled), AMD X870E Chipset1 x PCIe 4.0 x4 slot, 1 x PCIe 3.0 x1 slot |
| Сторидж: | Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*, AMD Ryzen™ 9000&7000 Series Desktop Processors***, M.2 1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), M.2 2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), M.2 3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), AMD Ryzen™ 8000 Series Desktop Processors, M.2 1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2 2 slot (Key M), type 2242/2260/2280 (Not supports), M.2 3 slot (Key M), type 2242/2260/2280 (Not supports), AMD X870E Chipset, DIMM.2 1 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe4.0 x4 mode), DIMM.2 2 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), 4 x SATA 6Gb/s ports, ** When M.2 2 and M.2 3 are enabled simultaneously, PCIEX16 2 will be disabled., ***When M.2 3 are enabled, PCIEX16 1 will run x8, and PCIEX16 2 will run x4, M.2 2 will be disabled., AMD RAIDXpert2 Technology, Ryzen™ 9000 Series Processors: RAID 0/1/5/10, Ryzen™ 8000 Series Processors: RAID 0/1, R |
| Графична карта: | 2 x USB4® (40Gbps) ports support USB Type-C® display outputs*, Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications., VGA resolution support depends on processors' or graphic cards' resolution., *Supports max. 4K@60Hz as specified in DisplayPort 1.4a |
| Звук: | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*, - Impedance sense for front and rear headphone outputs, - Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking, - High quality 120 dB SNR stereo playback output and 110 dB SNR recording input, - Supports up to 32-Bit/384 kHz playback on front panel", Audio Features, - SupremeFX Shielding Technology, - Savitech SV3H712 AMP, - Gold-plated audio jacks, - Rear optical S/PDIF out port, - Premium audio capacitors, - Audio cover, * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
| I/O: | 2 x USB4® (40Gbps) ports (2 x USB Type-C®), 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®), 2 x USB 5Gbps ports (2 x Type-A)1 x Wi-Fi module, 1 x Realtek 5Gb Ethernet port, 1 x PS/2 keyboard/mouse combo port, 2 x Gold-plated audio jacks1 x Optical S/PDIF out port, 1 x BIOS FlashBack™ button, 1 x ClearCMOS button |
| Мрежа: | 1 x Realtek 5Gb Ethernet, ASUS LANGuard |
| Конектори: | Fan and Cooling Related, 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header, 2 x 4-pin Chassis Fan headers, 2 x 4-pin Full Speed Fan headers, 1 x W PUMP+ header, 1 x Extra Flow Fan header, Power Related, 1 x 24-pin Main Power connector, 2 x 8-pin +12V CPU Power connector, 1 x 8-pin PCIe Power connectorStorage Related, 3 x M.2 slots (Key M), 4 x SATA 6Gb/s ports, USB, 2 x USB 20Gbps connectors (support USB Type-C® ), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports, Miscellaneous, 1 x 80 Light Bar jumper, 3 x Addressable Gen2 headers, 1 x Alteration PCIe mode switch, 2 x BCLK button, 1 x BIOS Switch button, 1 x FlexKey button, 1 x Front Panel Audioheader (F AUDIO), 1 x LN2 Mode jumper, 1 x Pause switch, 12 x ProbeIt Measurement Points, 1 x ReTry button, 2 x RSVD switches, 1 x RSVD 4 header, 1 x Safe Boot button, 1 x Slow Mode switch, 1 x Start button, 1 x 10-1 pin System Panel header, 1 x Thermal Sensor header |
| Форм фактор: | ATX Form Factor, 30.5 cm x 24.4 cm |
| Оперционни с-ми: | Windows 11 (22H2&later) |
| BIOS: | 2 x 256 Mb Flash ROM, UEFI AMI BIOS |
| USB: | Rear USB (Total 10 ports), 2 x USB4® (40Gbps) ports (2 x USB Type-C®), 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®) 2 x USB 5Gbps ports (2 x Type-A), Front USB (Total 10 ports), 1 x USB 20Gbps (supports USB Type-C® with up to 60W PD/QC4+)*, 1 x USB 20Gbps connector (supports USB Type-C®), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports, USB Type-C® power delivery output: max. 5V/3A, *USB Type-C® power delivery output: 5/9/15/20V max. 3A, PPS:3.321V max. 3A |
| Wireless: | Wi-Fi 7 (Qualcomm QCNCM865 or MediaTek MT7927), 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 320MHz bandwidth, Bluetooth® v5.4 |
| Features: | Extreme OC Kit, - FlexKey button, - LN2 Mode, - ProbeIt, - ReTry button, - Safe boot button, - Start button, - Slow Mode, Extreme Engine Digi+, - SMD Capacitor, - MicroFine alloy choke, ASUS Q-Design, - M.2 Q-Latch, - M.2 Q-Release, - M.2 Q-Slide, - Q-Release Slim (with PCIe SafeSlot), - Q-Antenna, - Q-Code, - Q-Connector, - Q-Dashboard, - Q-DIMM, - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]), ASUS Thermal Solution, - M.2 heatsink backplate, - M.2 heatsink, - VRM heatsink design, - Metal backplate, ASUS EZ DIY, - Backplate, - BIOS FlashBack™ button, - Clear CMOS button, - CPU Socket lever protector, - ProCool II, - Pre-mounted I/O shield, - SafeSlot, - SafeDIMM, Aura Sync, - Addressable Gen2 header(s), Front Panel USB 20Gbps with Quick Charge 4+ Support, - Support: up to 60W fast charging and USB Wattage Watcher*, - Output: 5/9/15/20V max. 3A,PPS:3.321V max. 3A, - Compatible with PD3.0 and PPS, * To support 60W, please install the power cable to the 8-pin PCIe power connector or else only 27W will be supported. |
| Bluetooth: | 5.4 |
