Подд. процесори: | - Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors |
Чипсет: | AMD B650 |
Памет/тип/: | Dual Channel DDR5 Memory Technology, - 2 x DDR5 DIMM Slots, - Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)*, - Max. capacity of system memory: 128GB, - Supports Extreme Memory Profile (XMP) and EXTended, Profiles for Overclocking (EXPO) memory modules |
Разш. слотове: | CPU, - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode, Chipset, - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*, - 15 Gold Contact in VGA PCIe Slot (PCIE1) |
Сторидж: | CPU, - 1 x Blazing M.2 Socket (M2 1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode, Chipset, - 1 x Hyper M.2 Socket (M2 2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*, - 2 x SATA3 6.0 Gb/s Connectors |
Графична карта: | Integrated AMD RDNA™ graphics (Actual support may vary by CPU), - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz |
Звук: | - 7.1 CH HD Audio (Realtek ALC897 Audio Codec), - Nahimic Audio |
I/O: | - 2 x Antenna Ports, - 1 x HDMI Port, - 3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32 23 are Lightning Gaming Ports.), - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s), - 4 x USB 2.0 Ports, - 1 x RJ-45 LAN Port, - 1 x BIOS Flashback Button, - HD Audio Jacks: Line in / Front Speaker / Microphone |
Мрежа: | - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s, - Dragon RTL8125BG, - Supports Phantom Gaming LAN Software, - Smart Auto Adjust Bandwidth Control, - Visual User Friendly UI, - Visual Network Usage Statistics, - Optimized Default Setting for Game, Browser, and Streaming Modes, - User Customized Priority Control |
Конектори: | - 2 x Addressable LED Headers*, - 2 x CPU/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**, - 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***, - 1 x 24 pin ATX Power Connector, - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector), - 1 x Front Panel Audio Connector, - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports), - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports), - 1 x Front Panel Type C USB 3.2 Gen1 Header |
Форм фактор: | - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm, - 8 Layer PCB |
Оперционни с-ми: | Microsoft Windows® 10 64-bit / 11 64-bit |
BIOS: | AMD B650 |
Други: | Wireless LAN: 802.11ax Wi-Fi 6E Module, - Supports IEEE 802.11a/b/g/n/ac/ax, - Supports Dual-Band 2x2 with extended 6GHz band* support, - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology, - Supports Bluetooth 5.2 + High speed class II, - Supports MU-MIMO |
Гаранция: | 36 Months |
Features: | Superb Productivity, - PCIe Gen5 (M.2), - Dual Channel DDR5, Rock-Solid Durability, - 8+2+1 Power Phase, 60A Dr.MOS with Enlarged Heatsink Armor, - Pre-Installed I/O Shield, - Flexible Integrated I/O Shield Ultrafast Gaming, - 2.5G LAN, 802.11ax Wi-Fi 6E Module, - ASRock Lightning Gaming Ports, EZ Update, - BIOS Flashback Button, - ASRock Auto Driver Installer |
