ASROCK Z790 RIPTIDE WIFI ASROCK Z790 4xDDR5 8xSATA3 RAID HDMI DP 5xM2 GLAN 2xPCIEx16 1xPCIEx1 WiFi - Z790-RIPTIDE

Дънна платка Asrock Z790 RIPTIDE WIFI

Парт.№: Z790-RIPTIDE
Кат.№: 135862
0 от 5 звезди! 0Коментара | Напиши коментар
Гаранция:   36 месеца
Цена с ДДС:  478 лв.BGN
Наличност: на склад
БЪРЗА ПОРЪЧКА   (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
  Съгласен съм с общите условия и начина на обработка на личните ми данни!

Подд. процесори:Supports 14th, 13th&12th Gen Intel® Core™ Processors (LGA1700),
- Supports Intel® Hybrid Technology,
- Supports Intel® Turbo Boost Max 3.0 Technology,
- Supports Intel® Thermal Velocity Boost (TVB),
- Supports Intel® Adaptive Boost Technology (ABT)
Чипсет:- Intel® Z790
Памет/тип/:Dual Channel DDR5 Memory Technology,
- 4 x DDR5 DIMM Slots,
- Supports DDR5 non-ECC, un-buffered memory up to 8000+(OC),
- Max. capacity of system memory: 256GB,
- Supports Intel Extreme Memory Profile (XMP) 3.0
Разш. слотове:CPU,
- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*,
Chipset,
- 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode,
- 1 x PCIe 3.0 x1 Slot (PCIE3),
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT),
- Supports AMD CrossFire™
Сторидж:CPU,
- 1 x Blazing M.2 Socket (M.2 GEN5, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode,
- 1 x Hyper M.2 Socket (M2 1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode,
Chipset,
- 1 x Hyper M.2 Socket (M2 2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode,
- 1 x Hyper M.2 Socket (M2 3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode,
- 1 x Hyper M.2 Socket (M2 4, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode,
- 8 x SATA3 6.0 Gb/s Connectors
Графична карта:- Intel® Xe Graphics Architecture (Gen 12),
- 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz,
- 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz,
- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Звук:- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec),
- Impedance Sensing on Rear Out port,
- Individual PCB Layers for R/L Audio Channel,
- Nahimic Audio
I/O:- 2 x Antenna Mounting Points,
- 1 x HDMI Port,
- 1 x DisplayPort 1.4,
- 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s),
- 1 x USB 3.2 Gen1 Type-C Port,
- 4 x USB 3.2 Gen1 Type-A Ports (USB32 56 are Lightning Gaming Ports.),
- 2 x USB 2.0 Ports,
- 1 x RJ-45 LAN Port,
- HD Audio Jacks: Line in / Front Speaker / Microphone
Мрежа:- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s,
- Killer E3100G,
- Supports Killer LAN Software
Конектори:- 1 x eDP Signal Connector,
- 1 x Thermistor Cable Header,
- 1 x SPI TPM Header,
- 1 x Power LED and Speaker Header,
- 1 x RGB LED Header,
- 3 x Addressable LED Headers,
- 1 x CPU Fan Connector (4-pin),
- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control),
- 1 x Chassis Fan Connector (4-pin),
- 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control),
- 1 x 24 pin ATX Power Connector,
- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector),
- 1 x Front Panel Audio Connector,
- 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card),
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports),
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports),
- 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
Форм фактор:- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm,
- 8 Layer PCB
Оперционни с-ми:Microsoft Windows® 10 64-bit / 11 64-bit
BIOS:- 128Mb AMI UEFI Legal BIOS with GUI support
Други:Wireless LAN: 802.11be 2x2 Wi-Fi 7 Module,
- Supports IEEE 802.11a/b/g/n/ac/ax/be,
- Supports 2.4GHz/5GHz/6GHz frequency band,
- Supports 320MHz channel bandwidth with 6GHz frequency band,
- 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology,
- Supports Bluetooth 5.4,
- Supports MU-MIMO
Гаранция:36 Months
Features:Superb Productivity,
- PCIe Gen5 (Graphics, M.2),
- Dual Channel DDR5,
Rock-Solid Durability,
- Server-Grade Low-Loss PCB,
- 16+1+1 Power Phase, 90A SPS for VCore+GT with Enlarged Heatsink Armor,
- Flexible Integrated I/O Shield,
- 20K Long-lasting Black Caps (high quality and conductive polymer capacitors),
Ultrafast Connectivity,
- Killer 2.5G LAN, 802.11be Wi-Fi 7 Module,
- ASRock Lightning Gaming Ports,
EZ Update,
- ASRock Auto Driver Installer,
EZ Troubleshooter
