| Manufacturer: | AXIS COMMUNICATIONS |
| Manufacturer Part No: | 02154-001 |
| General | |
| Device Type: | Thermal network camera |
| Audio Support: | Yes |
| Audio Formats: | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711 |
| Camera Mount Type: | Wall mount, ceiling mount |
| Connectivity Technology: | Wired |
| Width: | 13.2 cm |
| Depth: | 27.2 cm |
| Height: | 13.2 cm |
| Weight: | 1.4 kg |
| Localisation: | Argentina, Australia, China, Japan, Brazil, United Kingdom, United States, Europe |
| Camera | |
| Type: | Colour - Day&Night - fixed - outdoor - vandal / weatherproof |
| Digital Video Format: | MJPEG, H.264, H.265 |
| Max Digital Video Resolution: | 384 x 288 |
| Motion Detection: | Yes |
| Video Capture: | 384 x 288 @ 30 fps |
| RAM: | 1 GB |
| Flash Memory: | 512 MB |
| Features: | Sharpness control, digital image rotation, brightness control, contrast control, Object Detection, heater, Thermal Imaging System, Privacy Mask Function, Electronic Image Stabilizer (EIS), active tampering alarm, password protection, Variable Bitrate (VBR), Audio Detection, intrusion detection, Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, loitering detection, Pixel Counter Support, digest authentication, embedded SOC processor, IP address filtering, exposure zone, HTTPs encryption, uncooled micro bolometer, firmware upgradable, perimeter protection, Smart Motion Detection, secure boot, ONVIF (Profile T) support, Adaptive Bitrate (ABR), thermal sensitivity 40 mK (NETD), compression, user access log, brute force delay protection, Trusted Platform Module (TPM) |
| Image Sensor | |
| Type: | Uncooled Micro bolometer |
| Lens Construction | |
| Type: | Fixed focal |
| Focal Length: | 19 mm |
| Lens Iris: | F/1.23 |
| Min Focus Distance: | 8.5 m |
| Horizontal Field of View (degree): | 19.4 |
| Interfaces | |
| Network Interface: | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols: | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, IGMPv2, IGMPv3, CIFS, SRTP, EAP, SFTP, LLDP, USGv6, MQTT |
| Alarm Inputs Qty: | 1 |
| Alarm Outputs Qty: | 1 |
| Expansion / Connectivity | |
| Ports: | LAN/power - RJ-45 Audio line-in/microphone |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | |
| Included Accessories: | Wall mount bracket, ceiling mount bracket, connector guard, Resistorx L-key, terminal block connectors |
| Compliant Standards: | CISPR 24, EN55024, EN 61000-6-1, FIPS 140-2 Level 2, NEMA Type 4X, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, IP67, IK10, FCC Part 15 B Class A, IP66, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, AS/NZS, EN 50121-4, IEC 62236-4, VCCI Class A, NEMA TS-2, IEC 60950-22, EN 60529, EN 60950-22, UL 60950-22, IEC 60529, KN35, NEMA250 Type 4X, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, ISO 21207, RCM Class A, CISPR 32 Class A, IEEE 802.3af, IEEE 802.3at, UL 62368-1, IEC/EN 62262, EN 55035, CISPR 35, EN 60068-2-14, NIST SP500-267, MIL-STD-810H, ICES-3(A)/NMB-3(A), NEMA TS-2 (2.2.7-2.2.9), EN 60068-2-78 |
| Colour: | White |
| Power | |
| Power Requirements: | DC 12 - 28 V / PoE Class 3 |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 60 °C |
| Relative Humidity (operating): | 10 - 90% |
