Specifications
ModelCS-EB5-R100-2F8WFL
Camera
Image Sensor1/2.7” 8-Megapixel Progressive Scan CMOS Sensor
Minimum Illumination0.01 Lux @(F1.6, AGC ON), 0 Lux with IR
Shutter SpeedSelf-adaptive shutter
Lens2.8mm@ F1.6; 135° (Diagonal), 113° (Horizontal), 60° (Vertical)
Day & NightIR-Cut filter with auto-switching
DNR3D DNR
Night VisionIR Distance:15m, Color Night Vision Distance:15m
Video & Audio
Max. Resolution3840 × 2160
Frame Rate15fps. Self-Adaptive during network transmission
Video CompressionH.265 / H.264
Video Bit RateUltra HD; Quad HD; Full HD; Hi-Def Adaptive bit rate.
Audio Bit RateSelf-Adaptive
Max. Bitrate4 Mbps
Network
BluetoothSupports
Wi-Fi StandardIEEE802.11b, 802.11g, 802.11n, 802.11ax
Frequency Range2.4 GHz ~ 2.4835 GHz
Channel BandwidthSupports 20 MHz
SecurityWPA-PSK/WPA2-PSK, WPA3-Personal
Transmission Rate11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps
Wi-Fi PairingAP pairing
ProtocolEZVIZ Cloud proprietary protocol
Interface ProtocolEZVIZ Cloud proprietary protocol
Minimum Network Requirement8Mbps
Function
Smart AlarmAI-Powered Human Shape Detection, AI-Powered Vehicle Detection
Two-way TalkSupports
General FunctionAnti-Flicker, Heart Beat, Password Protection, Watermark
Storage
Local StorageSupports Micro SD slot for local storage (Up to 512G)
Cloud StorageEZVIZ cloud storage
General
Operating Conditions-20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing)
IP GradeIP65
Power SupplyDC 5V/2A (Compatible power adapter needs to be purchased separately)
Battery Capacity10400 mAh
Power ConsumptionMax. 10W
Product Dimensions166 × 103 × 54 mm
Packaging Dimensions227 × 167 × 64 mm
Weight
Net Weight: 466g
With Package: 822g
In the box
- Camera
- Power Cable
- Screw Base
- Drill Template
- EZVIZ Screw Kit
- Regulatory Information
- Quick Start Guide
