Specifications
ModelCS-H9c-R100-8H33WKFL
Camera
Image Sensor1/2.7" Progressive Scan CMOS
Shutter SpeedSelf-adaptive shutter
LensUpper Camera: 2.8mm@ F1.6, viewing angle: Diagonal 130°, Horizontal 108°, Vertical 56° Bottom Camera: 6mm@F1.6, viewing angle: Diagonal 62°, Horizontal 55°, Vertical 28°
PT AnglePan: 350°, Tilt: 80°
Minimum Illumination0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
Lens MountM12
Day & NightIR-cut filter with auto-switching
DNR3D DNR
WDRDigital WDR
Black & White Night30m / 98ft
Video & Audio
Max Resolution2304 × 1296
Frame RateMax:15fps; Self-Adaptive during network transmission
Video CompressionH.265 / H.264
H.265 TypeMain Profile
Video Bit RateQuad HD, Full HD, Hi Def, Standard. Adaptive bit rate.
Audio Bit RateSelf-Adaptive
Network
Wi-Fi StandardIEEE802.11b, 802.11g, 802.11n
Frequency Range2.4 GHz ~ 2.4835 GHz
Channel BandwidthSupports 20MHz
Transmission Rate11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps
Wi-Fi PairingAP paring
ProtocolEZVIZ cloud proprietary protocol
Interface ProtocolEZVIZ cloud proprietary protocol
Wired NetworkRJ45 × 1 (10M / 100M Adaptive Ethernet Port)
SecurityWPA-PSK/WPA2-PSK
Functions
Smart AlarmAI-Powered Human Shape Detection / AI-Powered Vehicle Shape Detection / Motion Detection
Auto TrackingSupports
Customized Alert AreaSupports
Two-way TalkSupports
Preset LocationsSupports
General FunctionAnti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
Storage
Local StorageSupports microSD Card (Up to 512 GB)
Cloud StorageSupports EZVIZ CloudPlay storage
General
Operating Conditions-30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)
IP GradeWeatherproof Design
Power SupplyDC 12V/1.5A
Power ConsumptionMAX. 12W
Dimensions145 × 116 × 142mm (5.71 × 4.57 × 5.59 inch)
Packaging Dimensions150 × 150 × 194mm (5.90 × 5.90 × 7.64 inch)
Weight
Net Weight: 668 g
With Package: 960 g
In the box
- H9c Camera
- Drill Template
- Screw Kit
- Waterproof Kit
- Power Adapter
- Regulatory Information
- Quick Start Guide
