| Manufacturer: | HP INC. |
| Manufacturer Part No: | D4DB3ET#ABB |
| General |
| Type: | Workstation |
| AI Level: | AI PC, AI Workstation |
| Product Form Factor: | Mini |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Colour: | Black |
| Localisation: | Language: English / region: Europe |
| Processor / Chipset |
| CPU: | NVIDIA GB10 Grace Blackwell Superchip Cortex-A725 + Cortex-X925 |
| Number of Cores: | 20-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| RAM |
| Installed Size: | 128 GB |
| Technology: | LPDDR5X SDRAM |
| Effective Memory Speed: | 8533 MT/s |
| Configuration Features: | Provided memory is soldered |
| Hard Drive |
| Type: | SSD - M.2 |
| Capacity: | 1 x 2 TB |
| Interface Type: | PCI Express 4.0 |
| Features: | NVM Express (NVMe), triple-level cell (TLC) |
| Storage Controller |
| Type: | 1 x NVMe |
| Optical Storage |
| Type: | No optical drive |
| Monitor |
| Monitor Type: | None. |
| Graphics Controller |
| Graphics Processor: | NVIDIA Blackwell |
| Video Interfaces: | HDMI |
| Input Device |
| Type: | No keyboard, no mouse |
| Networking |
| Ethernet Ports: | 1 x 10 Gigabit Ethernet, 2 x 200 Gigabit Ethernet QSFP |
| Ethernet Controller: | Realtek RTL8127-CG, Mellanox ConnectX-7 |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | MediaTek Wi-Fi 7 MT7925 |
| Data Link Protocol: | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n, Bluetooth 5.4, Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, 200 Gigabit Ethernet, 5 Gigabit Ethernet |
| Features: | Wake on LAN (WoL), PXE support, dual stream (2x2) |
| Compliant Standards: | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1ad, IEEE 802.1as, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3ck |
| Expansion / Connectivity |
| Interfaces: | 3 x USB-C 3.2 Gen 2x2/DisplayPort 1.4a (3 rear) (30 Watt output) 1 x USB-C (1 rear) (powered 240W) 1 x HDMI (1 rear) 1 x LAN (10Gigabit Ethernet) - RJ-45 (1 rear) 2 x LAN (200 Gigabit Ethernet) - QSFP (2 rear) |
| Miscellaneous |
| Compliant Standards: | FIPS 140-2, CEC, ERP, CECP, RoHS, CEL, GS, UL, CB, BIS, EMC, FCC, ICES, CCC, Common Criteria EAL4+ |
| Power |
| Device Type: | Power adapter |
| Voltage Required: | AC 90-264 V (50/60 Hz) |
| Power Provided: | 240 watt |
| Efficiency: | 89% |
| Power Factor Correction: | Yes (active) |
| Operating System / Software |
| OS Provided: | NVIDIA DGX Base OS |
| Software: | NVIDIA AI Software Stack |
| Dimensions & Weight |
| Width: | 15 cm |
| Depth: | 15 cm |
| Height: | 5.45 cm |
| Weight: | 1.25 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width: | 21.6 cm |
| Shipping Depth: | 14.2 cm |
| Shipping Height: | 27.2 cm |
| Shipping Weight: | 2.5 kg |
| Environmental Parameters |
| Min Operating Temperature: | 5 °C |
| Max Operating Temperature: | 30 °C |
| Humidity Range Operating: | 8 - 85% RH (non-condensing) |
