Парт.№: C9300X-24Y-A
Кат.№: 140633
Кат.№: 140633
Цена с ДДС:
41386 лв.
Цена с ДДС:
21160.32 €
с поръчка
БЪРЗА ПОРЪЧКА (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
Гаранция: 99 месеца
| Manufacturer: | CISCO |
| Manufacturer Part No: | C9300X-24Y-A |
| General | |
| Device Type: | Switch - 24 ports - L3 - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Subtype: | 25 Gigabit Ethernet |
| Ports: | 24 x 1/10/25 Gigabit SFP28 |
| Performance: | Switching capacity: 2000 Gbps Switching capacity with stacking: 3000 Gbps Forwarding rate: 1488 Mpps Forwarding rate with stacking: 2232 Mpps Stacking bandwidth: 1 Tbps |
| Capacity: | IPv4 routing table entries: 39000 IPv6 routing table entries: 19500 Flexible NetFlow entries: 128000 VLAN IDs: 4094 Switched virtual interfaces (SVIs): 1000 Packet buffer size: 32 MB MAC addresses: 32000 Multicast routing flow table: 8000 QoS scale entries: 4000 ACL scale entries: 5000 PVST instances: 1000 STP Virtual Ports for PVST: 13000 STP Virtual Ports for MST: 1000 Jumbo frame size: 9198 byte |
| MAC Address Table Size: | 32000 entries |
| Jumbo Frame Support: | 9198 bytes |
| Routing Protocol: | OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| Encryption Algorithm: | 128-bit AES |
| Features: | DHCP support, trunking, Syslog support, full duplex mode, SSO, CBWFQ, WRED, STP support, ACL support, QoS, NSR, RSPAN, MIB, Cisco StackWise-480 technology, Cisco StackPower technology, FNF, MSDP, 802.1x authentication, 16MB packet buffer, FTP client, MACsec support, 3 fans, CoPP, VXLAN, AVC, SSM, integrated Wireshark, VLAN Double Tagging (Q-in-Q), EoMPLS, H-VPLS, Private VLAN, L3VPN support, ERSPAN, SGT caching, SGACL, ITSM integration, third-party IPAM integration, Cisco StackWise-1T technology |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at |
| RAM: | 16 GB |
| Flash Memory: | 16 GB |
| Status Indicators: | Status |
| Expansion / Connectivity | |
| Interfaces: | 24 x 1/10/25GBase-X SFP28 1 x USB 2.0 |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Power | |
| Power Device: | Internal power supply - hot-plug |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Redundancy: | Yes |
| Power Provided: | 715 Watt |
| Voltage Required: | AC 120/230 V (50 - 60 Hz) |
| Miscellaneous | |
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1 |
| Software / System Requirements | |
| OS Required: | Cisco IOS Universal |
| Dimensions & Weight | |
| Width: | 44.5 cm |
| Depth: | 44.7 cm |
| Height: | 4.4 cm |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - replacement - lifetime - response time: next business day Technical support - consulting - 90 days |
| Environmental Parameters | |
| Min Operating Temperature: | -5 °C |
| Max Operating Temperature: | 45 °C |
| Humidity Range Operating: | 5 - 90% (non-condensing) |
| Min Storage Temperature: | -40 °C |
| Max Storage Temperature: | 70 °C |
| Humidity Range Storage: | 5 - 90% (non-condensing) |
