Manufacturer: | HEWLETT PACKARD ENTERPRISE |
Manufacturer Part No: | P71674-425 |
General |
Type: | Server |
Product Form Factor: | Rack-mountable - 2U |
Built-in Devices: | Led panel |
Embedded Security: | Trusted Platform Module (TPM) Security Chip |
Server Scalability: | 2-way |
Hot-Swap Bays Qty: | 8 |
Localisation: | Region: Germany, Switzerland, Austria, France, United Kingdom, Scotland, Ireland |
Processor / Chipset |
CPU: | Intel Xeon Silver 4510 |
Clock Speed: | 2.4 GHz |
Max Turbo Speed: | 4.1 GHz |
Number of Cores: | 12-core |
CPU Qty: | 1 |
Max CPU Qty: | 2 |
CPU Upgradability: | Upgradable |
Chipset Type: | Intel C741 |
Cache Memory |
Installed Size: | 30 MB |
Cache Per Processor: | 30 MB |
RAM |
Installed Size: | 64 GB (installed) / 8 TB (max) |
Technology: | DDR5 SDRAM |
Effective Memory Speed: | 4400 MHz |
Rated Memory Speed: | 5600 MHz |
Form Factor: | DIMM 288-pin |
Slots: | 32 (Total) / 30 (empty) |
Features: | HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only |
Configuration Features: | 2 x 32 GB |
Hard Drive |
Type: | SSD - 2.5" |
Capacity: | 2 x 960 GB |
Interface Type: | SATA |
Storage Controller |
Type: | 1 x RAID - OCP |
Controller Interface Type: | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
Channel Qty: | 8 |
RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
Buffer Size: | 4 GB |
Optical Storage |
Type: | No optical drive |
Monitor |
Monitor Type: | None. |
Graphics Controller |
Video Memory: | 16 MB |
Video Interfaces: | VGA |
Networking |
Interface (Bus) Type: | Open Compute Project mezzanine (OCP) 3.0 |
Ethernet Ports: | 4 x Gigabit Ethernet |
Ethernet Controller: | Broadcom BCM5719 |
Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Controller: | Integrated Lights-Out 6 |
Features: | Wake on LAN (WoL), PXE support |
Compliant Standards: | OCP 3.0 |
Expansion / Connectivity |
Bays: | 1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 8 (free) x hot-swap 2.5" SFF |
Slots: | 2 (total) / 2 (free) x FlexibleLOM 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode) 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode) |
Interfaces: | 1 x USB 3.0 (1 in front) (HPE iLO Service Port) 4 x USB 3.0 (2 rear, 2 internal) 1 x HPE iLO - RJ-45 (1 rear) 1 x VGA (1 rear) 4 x LAN (Gigabit Ethernet) |
Miscellaneous |
Included Accessories: | HPE Easy Install Rails |
Compliant Standards: | AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2, low halogen, Triple DES, SMBIOS 3.2, Redfish API |
Manufacturer Selling Program: | HPE Smart Choice |
Power |
Device Type: | Power supply - hot-plug |
Power Redundancy: | Yes |
Power Redundancy Scheme: | 1+1 |
Installed Qty: | 2 |
Max Supported Qty: | 2 |
Voltage Required: | AC 100-240 V |
Power Provided: | 1000 Watt |
80 PLUS Certification: | 80 PLUS Titanium |
Operating System / Software |
OS Provided: | No operating system |
OS Certified: | Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux |
Software: | HPE Server UEFI |
Manufacturer Warranty |
Service & Support: | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
Dimensions & Weight |
Width: | 44.8 cm |
Depth: | 72.7 cm |
Height: | 8.75 cm |
Weight: | 16 kg |
Environmental Parameters |
Min Operating Temperature: | 10 °C |
Max Operating Temperature: | 35 °C |
Humidity Range Operating: | 8 - 90% RH (non-condensing) |
