Fujitsu Primergy RX2520 M5 4X3.5'' LFF, 1 x Intel Xeon Silver 8 Core 4208 16GB DDR4-2933 ECC R DIMM HP PSU 800W - VFY:R2525SC180IN
Парт.№: VFY:R2525SC180IN
Кат.№: 146319
Кат.№: 146319
Информация от производителБЪРЗА ПОРЪЧКА (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
Гаранция: 36 месеца
| Manufacturer: | FUJITSU TECHNOLOGY SOLUTIONS |
| Manufacturer Part No: | VFY:R2525SC180IN |
| General | |
| Type: | Server |
| Product Form Factor: | Rack-mountable - 2U |
| Server Scalability: | 2-way |
| Front Accessible Bays Qty: | 1 |
| Hot-Swap Bays Qty: | 4 |
| Processor / Chipset | |
| CPU: | Intel Xeon Silver 4208 |
| Clock Speed: | 2.1 GHz |
| Max Turbo Speed: | 3.2 GHz |
| Number of Cores: | 8-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Chipset Type: | Intel C624 |
| Cache Memory | |
| Installed Size: | 11 MB |
| Cache Per Processor: | 11 MB |
| RAM | |
| Installed Size: | 16 GB (installed) / 768 GB (max) |
| Technology: | DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed: | 2400 MHz |
| Rated Memory Speed: | 2933 MHz |
| Slots: | 12 (Total) / 11 (empty) |
| Features: | Memory Mirroring, slots 7 - 12 are available in two-processor configuration only, Independent Memory Mode, memory rank sparing, memory scrubbing |
| Configuration Features: | 1 x 16 GB |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x SATA |
| Controller Interface Type: | SATA 6Gb/s |
| RAID Level: | RAID 0, RAID 1 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Video Interfaces: | VGA |
| Networking | |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | IPMI 2.0 |
| Remote Management Controller: | Integrated Remote Management Controller (iRMC S5) |
| Features: | Wake on LAN (WoL), PXE support |
| Expansion / Connectivity | |
| Bays: | 4 (total) / 4 (free) x hot-swap 3.5" LFF 1 (total) / 1 (free) x external 5.25" |
| Slots: | 3 (total) / 3 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile 2 (total) / 2 (free) x PCIe 3.0 x16 - low-profile (2 processors must be installed) |
| Interfaces: | 7 x USB 3.0 (2 front, 4 rear, 1 internal) 1 x VGA 1 x management - RJ-45 2 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Compliant Standards: | FCC Class A certified, BSMI, GS, CB, ICES-003 Class A, RoHS, WEEE, KC, VCCI V-3 Class A ITE, cCSAus, JIS C 61000-3-2, EAC, NMB-3 Class A, RCM |
| Power | |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Installed Qty: | 1 |
| Max Supported Qty: | 2 |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Power Provided: | 800 Watt |
| Operating System / Software | |
| OS Provided: | No operating system |
| Software: | iRMC S5 Advanced Pack |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years - on-site |
| Dimensions & Weight | |
| Width: | 48.23 cm |
| Depth: | 77 cm |
| Height: | 8.66 cm |
| Environmental Parameters | |
| Min Operating Temperature: | 5 °C |
| Max Operating Temperature: | 45 °C |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
