| Power - UPS - Design&Features |
| UPS Technology: | Double Conversion Online |
| Output Power Capacity: | 2700 W |
| Maximum Electrical Power Rating: | 3000 VA |
| Nominal Output Voltage: | 200/240 V |
| Voltage Phase: | Single |
| Diagnostics: | Alarm Test |
| Status Notification Method: | LCD |
| Circuit Protection: | Fuse Over Current Over Load Overcharge Overheating Protection Circuit Breaker |
| Surge Suppression: | Yes |
| Maximum Surge Energy Rating: | 370 J |
| Power - UPS - Output Characteristics |
| Output Waveform: | Pure Sinewave |
| Maximum Output Voltage: | 240 V |
| Minimum Output Voltage: | 208 V |
| Maximum Output Frequency: | 60 Hz |
| Minimum Output Frequency: | 50 Hz |
| Output Power Connectors Quantity: | 8 |
| Output Power Connectors |
| IEC-320 C19: | 1 |
| Hardwire: | 1 |
| IEC-320 C13: | 6 |
| Power - UPS - Input Characteristics |
| Maximum Input Voltage: | 300 V |
| Minimum Input Voltage: | 190 V |
| Maximum Input Frequency: | 60 Hz |
| Minimum Input Frequency: | 50 Hz |
| Input Power Connectors Quantity: | 1 |
| Input Power Connectors Type: | IEC-320 C20 |
| Power - UPS - Battery |
| Battery Backup Time at Full Load: | 4.2 min |
| Battery Backup Time at Half Load: | 13.1 min |
| Battery Recharge Time: | 4 hr |
| Power - UPS - Interface Provided |
| Management Port Connector Type: | RS-232 9-pin D-Sub |
| Power - UPS - Environment |
| Maximum Operating Ambient Temperature: | 40 °C |
| Maximum Operating Humidity: | 90 % |
| Minimum Operating Ambient Temperature: | 0 °C |
| Minimum Operating Humidity: | 20 % |
| Maximum Non-Operating Ambient Temperature: | 50 °C |
| Maximum Non-Operating Humidity: | 90 % |
| Minimum Non-Operating Ambient Temperature: | -20 °C |
| Minimum Non-Operating Humidity: | 10 % |
| Power - UPS - Miscellaneous |
| External Color: | Black |
| Mounting Capability: | Stand Alone |
| Included Accessories: | Quick Start Guide |
| Power - UPS - Dimensions&Weight |
| Depth (mm): | 416 mm |
| Height (mm): | 337 mm |
| Width (mm): | 196 mm |
| Nominal Weight: | 26 kg |
| Warranty |
| Warranty Products Returnable: | Yes |
| Warranty Term (month): | 24 month(s) |
| Warranty Validation Criteria: | Serial Number |
| Logistic |
| Pack Weight Brutto (kg): | 26 kg |
| Pack Weight Netto (kg): | 26 kg |
| Pieces in pack: | 1 |
| Box Weight Brutto (kg): | 26 kg |
| Retail Packaging Net Weight Carton: | 26 kg |
| Retail Packaging Net Weight Plastic: | 26 kg |
| Packs in Box: | 1 |
| Package Type: | Retail |
