Парт.№: CGR GEXP-850
Кат.№: 146197
Кат.№: 146197
Цена с ДДС:
327 лв.
Цена с ДДС:
167.19 €
на склад
БЪРЗА ПОРЪЧКА (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
| Design&Features | |
| Power Device Type: | Power Supply |
| Power Device Location: | Plug-in-module |
| Form Factor: | ATX |
| Input Voltage: | AC 100-240 V |
| Input Frequency: | 50/60 Hz |
| Input Power Connectors Quantity: | 1 |
| Rated Current: | 12 A |
| Maximum Output Power: | 850 W |
| Circuit Protection: | Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power |
| Modular Power Supply: | Yes |
| 80 Plus Certification: | 80 Plus Gold |
| Efficiency: | 91% |
| Currents | |
| +3.3V: | 20 A (50 W) |
| +5V: | 20 A (50 W) |
| +12V: | 70.8 A (849.6 W) |
| -12V: | 0.3 A (3.6 W) |
| +5VSB: | 3 A (15 W) |
| Output Connectors | |
| 20+4-pin Main Connector: | 1 |
| 4/8-pin +12V Power Connector: | 2 |
| 4-pin Peripheral Power Connector: | 3 |
| S-ATA Connector: | 8 |
| 6/8-pin PCI Express Connector: | 3 |
| 16-pin PCI Express 5.0 Connector: | 1 |
| Environment | |
| Maximum Operating Ambient Temperature: | 40 °C |
| Minimum Operating Ambient Temperature: | 10 °C |
| Maximum Non-Operating Ambient Temperature: | 70 °C |
| Minimum Non-Operating Ambient Temperature: | -40 °C |
| Maximum Operating Humidity: | 85 % |
| Minimum Operating Humidity: | 20 % |
| Maximum Non-Operating Humidity: | 95 % |
| Minimum Non-Operating Humidity: | 5 % |
| Miscellaneous | |
| External Color: | Black |
| Cable Included: | Modular Cables |
| Included Accessories: | Quick Start Guide |
| Dimensions & Weight Device | |
| Depth (mm): | 140 mm |
| Height (mm): | 86 mm |
| Width (mm): | 150 mm |
| Warranty | |
| Warranty Products Returnable: | Yes |
| Warranty Term (month): | 24 month(s) |
| Warranty Validation Criteria: | Serial Number |
| Logistic | |
| Pack Weight Brutto (kg): | 2.19 kg |
| Pack Weight Netto (kg): | 11.2 kg |
| Pieces in pack: | 1 |
| Box Weight Brutto (kg): | 12 kg |
| Retail Packaging Net Weight Carton: | 0.17 kg |
| Retail Packaging Net Weight Plastic: | 0.03 kg |
| Packs in Box: | 5 |
| Package Type: | Box |
| EAN Code: | 4710483778674 |
| GPSR | |
| Economic operator in EU / authorized representative: | COMPUCASE Enterprise Co., Ltd. |
| Postal address: | No. 225, Lane 54, An-Ho Rd., Sec.2, Tainan, Taiwan R.O.C. |
