ASUS PRIME B550-PLUS ASUS B550 4xDDR4 6xSATA3 RAID HDMI DP 2xM2 GLAN 2xPCIEx16 3xPCIEx1 - 90MB14U0-M0EAY0

Дънна платка Asus PRIME B550-PLUS

Парт.№: 90MB14U0-M0EAY0
Кат.№: 135922
0 от 5 звезди! 0Коментара | Напиши коментар
Гаранция:   36 месеца
Цена с ДДС:  235 лв.BGN
Наличност: на склад
БЪРЗА ПОРЪЧКА   (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
  Съгласен съм с общите условия и начина на обработка на личните ми данни!

Подд. процесори:Build in AMD AM4 Socket 3rd Gen AMD Ryzen™ Processors *
Чипсет:AMD B550
Памет/тип/:4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory * Next Generation AMD Ryzen PRO Processors,
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory Dual Channel Memory Architecture
Разш. слотове:3rd Gen AMD Ryzen™ Processors: 1 x PCIe 4.0 x16 (x16 mode),
AMD B550 Chipset: 1 x PCIe 3.0 x16 (x4 mode),
3 x PCIe 3.0 x1 *1
Сторидж:Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports,
3rd Gen AMD Ryzen™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA&PCIe 4.0 x4 mode),
AMD B550 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA&PCIE 3.0 x 4 mode)*2,
6 x SATA 6Gb/s port(s), *2,
Support Raid 0, 1, 10
Графична карта:1 x DisplayPort 1.2 *,
1 x HDMI 2.1(4K@60HZ)
Звук:Realtek ALC887 7.1-Channel High Definition Audio CODEC,
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback,
Audio Feature : - Optical S/PDIF out port(s) at back panel,
- LED-illuminated design,
- Audio Shielding,
- Dedicated audio PCB layers,
- Premium Japanese audio capacitors,
- Unique de-pop circuit
I/O:1 x DisplayPort,
1 x HDMI,
1 x LAN (RJ45) port(s),
2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®),
4 x USB 3.2 Gen 1 (blue) Type-A,
2 x USB 2.0,
1 x Optical S/PDIF out,
5 x Audio jack(s)
Мрежа:Realtek® RTL8111H,
ASUS LANGuard
Конектори:1 x CPU Fan connector(s),
1 x CPU OPT Fan connector(s),
3 x Chassis Fan connector(s),
1 x AIO PUMP connector,
2 x Aura RGB Strip Headers,
1 x Addressable Gen 2 header(s),
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s),
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support(SATA&PCIe 4.0 x4 mode),
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA&PCIE 3.0 x 4 mode),
1 x SPI TPM header,
6 x SATA 6Gb/s connector(s),
1 x Thunderbolt header(s),
1 x 24-pin EATX Power connector(s),
1 x 8-pin EATX 12V Power connectors,
1 x Front panel audio connector(s) (AAFP),
1 x Thermal sensor connector(s),
1 x Clear CMOS jumper(s),
1 x System panel connector,
1 x COM port header
Форм фактор:ATX Form Factor,
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Оперционни с-ми:Windows® 10 64-bit
BIOS:256 Mb Flash ROM, UEFI AMI BIOS
Гаранция:36 Months
