Парт.№: 90MB1DV0-M0EAY0
Кат.№: 131851
Кат.№: 131851
Цена с ДДС:
1035 лв.
Цена с ДДС:
529.19€
с поръчка
БЪРЗА ПОРЪЧКА (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
Гаранция: 36 месеца
| Manufacturer: | ASUS |
| Manufacturer Part No: | 90MB1DV0-M0EAY0 |
| General | |
| Product Type: | Motherboard - ATX |
| Chipset Type: | Intel Z790 |
| Processor Socket: | LGA1700 Socket |
| Max Processors Qty: | 1 |
| Compatible Processors: | (supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron) |
| Supported RAM | |
| Max Size: | 128 GB |
| Technology: | DDR5 |
| Bus Clock: | 4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.) |
| Supported RAM Integrity Check: | Non-ECC |
| Registered or Buffered: | Unbuffered |
| Features: | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Audio | |
| Type: | HD Audio (8-channel) |
| Audio Codec: | Realtek ALCS1220A |
| Compliant Standards: | High Definition Audio |
| LAN | |
| Network Interfaces: | 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
| Expansion / Connectivity | |
| Expansion Slots: | 1 x CPU 4 x DIMM 288-pin 2 x PCIe 5.0 x16 (dual x8 mode; single card: x16 mode) 1 x PCIe 4.0 x16 (x4 mode) 2 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot) 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) 1 x M.2 socket (Key E) |
| Storage Interfaces: | SATA-600 -connectors: 8 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 5 SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 5 |
| RAID Features: | Intel Rapid Storage Technology |
| Interfaces: | 2 x Thunderbolt 4/USB4 1 x HDMI 6 x USB 3.2 Gen 2 1 x audio line-in - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x LAN (10Gigabit Ethernet) 1 x LAN (2.5Gigabit Ethernet) 2 x DisplayPort input 2 x aerial |
| Internal Interfaces: | 4 x USB 2.0 - header 1 x USB-C 3.2 Gen 2x2 - header 2 x USB 3.2 Gen 1 - header 1 x serial - header 1 x audio - header 1 x SPI - header |
| Power Connectors: | 24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector, 6-pin ATX12V connector |
| Features | |
| BIOS Features: | UEFI BIOS, ASUS EZ Flash 3, MemTest86, ASUS UEFI BIOS EZ Mode |
| Sleep / Wake Up: | Wake on LAN (WOL), wake on PME |
| Hardware Features: | Intel Turbo Boost Technology 2.0, Intel Turbo Boost Max Technology 3.0, ASUS OptiMem II, audio jack detect technology, jack retasking, LANGuard, FlexKey button, CrashFree BIOS 3, Preboot eXecution Environment (PXE), BIOS FlashBack button, ASUS 5X Protection III, ASUS Aura Sync, ASUS DIGI+ VRM, ASUS Enhanced DRAM Overcurrent Protection, ASUS EZ DIY, ASUS ProCool II, ASUS Q-Connector, ASUS Q-Design, ASUS SafeSlot, ASUS Stainless Steel Back I/O, BIOS FlashBack LED, ESD Guards, M.2 heatsink, M.2 Q-Latch, overvoltage protection, pre-mounted I/O shield, Q-DIMM, Q-LED, Q-Slot, VRM heatsink design, Quick Charge 4+, 16+1 Phase Power Design, ASUS Enhanced Memory Profile (AEMP) II |
| Miscellaneous | |
| Software Included: | Armoury Crate, ASUS AI Suite III, ASUS CPU-Z, ASUS Control Center Express, ASUS ProArt Creator Hub, CreationFirst, MyAsus, Norton 360 Deluxe (60 days trial), WinRAR |
| Compliant Standards: | DisplayPort 1.4 |
| Width: | 30.5 cm |
| Depth: | 24.5 cm |
