ASROCK B650E PG RIPTIDE WIFI ASROCK B650 4xDDR5 4xSATA3 RAID HDMI DVI 3xM2 GLAN 2xPCIEx16 1xPCIEx1 WiFi - B650E_TSM
Парт.№: B650E_TSM
Кат.№: 134011
Кат.№: 134011
Цена с ДДС:
414 лв.
Наличност:
изчерпан
Гаранция: 36 месеца
| Подд. процесори: | - Supports AMD Socket AM5 Ryzen™ 7000 Series Processors |
| Чипсет: | - AMD B650 |
| Памет/тип/: | - Dual Channel DDR5 Memory Technology, - 4 x DDR5 DIMM Slots, - Supports DDR5 non-ECC, un-buffered memory up to 6600+(OC)*, - Max. capacity of system memory: 128GB, - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules |
| Разш. слотове: | CPU: - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*, - 1 x PCIe 3.0 x16 Slot (PCIE3), supports x4 mode*, Chipset: - 1 x PCIe 4.0 x1 Slot (PCIE2)*, - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*, - Supports AMD CrossFire™, - 15 Gold Contact in VGA PCIe Slot (PCIE1) |
| Сторидж: | CPU: - 1 x Blazing M.2 Socket (M2 1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*, Chipset: - 1 x M.2 Socket (M2 2, Key M), supports type 2242/2260/2280 SATA3 6.0 Gb/s&PCIe Gen3x2 (16 Gb/s) modes*, - 1 x Hyper M.2 Socket (M2 3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*, - 2 x SATA3 6.0 Gb/s Connectors, ASMedia ASM1061: - 2 x SATA3 6.0 Gb/s Connectors |
| Графична карта: | Integrated AMD RDNA™ 2 graphics (Actual support may vary by CPU), - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz |
| Звук: | - 7.1 CH HD Audio (Realtek ALC897 Audio Codec), - Nahimic Audio |
| I/O: | - 2 x Antenna Ports, - 1 x HDMI Port, - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver), - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver), - 2 x USB 3.2 Gen1 Ports (USB32 23 are Lightning Gaming Ports), - 6 x USB 2.0 Ports, - 1 x RJ-45 LAN Port, - 1 x BIOS Flashback Button, - HD Audio Jacks: Line in / Front Speaker / Microphone |
| Мрежа: | - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s, - Killer E3100G, - Supports Killer LAN Software |
| Конектори: | - 1 x SPI TPM Header, - 1 x Power LED and Speaker Header, - 1 x RGB LED Header*, - 3 x Addressable LED Headers**, - 1 x CPU Fan Connector (4-pin)***, - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****, - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****, - 1 x 24 pin ATX Power Connector, - 1 x 8 pin 12V Power Connector, - 1 x 4 pin 12V Power Connector, - 1 x Front Panel Audio Connector, - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card), - 2 x USB 2.0 Headers (Support 3 USB 2.0 ports), - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports), - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (ReDriver) |
| Форм фактор: | - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm, - 8 Layer PCB |
| Оперционни с-ми: | - Microsoft® Windows® 10 64-bit / 11 64-bit |
| BIOS: | - 256Mb AMI UEFI Legal BIOS with GUI support |
| Други: | - 802.11ax Wi-Fi 6E Module, - Supports IEEE 802.11a/b/g/n/ac/ax, - Supports Dual-Band 2x2 with extended 6GHz band support*, - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology, - Supports Bluetooth 5.2 + High speed class II, - Supports MU-MIMO |
| Гаранция: | 36 Months |
