Features

Max. resolution: 4MP (2560 × 1440)

Motorized lens：2.8~12mm

Auto day/night switch

3D DNR, HWDR, HLC, BLC, etc.

ROI coding

Support smart supplement light

30~40m white light view distance; 30~40m IR view distance

DC12V/PoE power supply

IP 66 ingress protection

Support three streams

Support remote monitoring by smart phones& tablet PCs with iOS and Android OS

Support P2P function

Support SMD

Support line crossing detection, region intrusion detection,abandoned/missing object detection, video exception detection

Blue and red light warning (flashing alternately)

Support user-defined warning voice import

Specification

Model	TD-9545S4-PA
Camera
Image Sensor	1 / 3 "CMOS
Image Size	2560×1440
Electronic Shutter	1/1s ~ 1 / 100000s
Iris Type	Fixed Iris
Min. Illumination	0.005 lux @F1.6, AGC ON; 0 lux with illumination on 0.004 lux @F1.4, AGC ON; 0 lux with illumination on
Lens			2.8~12mm@F1.4,H.FoV: 92 °~31 °; V.FoV: 48 °~17.2°;D.FoV: 112 °~ 35.6 °
Focus			Motorized
Lens Mount	M12		Ø 14
Day/Night	Auto, Day, Night, Timing
Wide Dynamic Range	120dB
BLC	Yes
HLC	Yes
Digital NR	Yes
	≥
S/N Ratio	50dB
Angle Adjustment	Pan: 0°~360°; Tilt:0°~80°;Rotation: 0°~360°
Video Compression	Main stream: H.265+ /  H.265  /  H.264+  /  H.264 Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG Third stream: H.265+ / H.265 / H.264+ / H.264/ MJPEG
H.265 Compression Standard	Main Profile@Leve4.1 High Tier
Resolution	4MP (2560×1440 ), 3MP (2304×1296 ),1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, VGA (640 × 480), CIF, 480 × 240
Main Stream	60Hz: 4MP/3MP/1080P/720P(1~30fps); 50Hz: 4MP/3MP/1080P/720P(1~25fps)
Sub Stream	60Hz : 720P/D1/VGA/CIF(1~30fps); 50Hz: 720P/D1/VGA/CIF (1~25fps)
Third Stream	60Hz: D1/480× 240/CIF (1~30fps);50Hz: D1/480× 240/CIF(1~25fps)
Bit Rate	64 Kbps ~ 6 Mbps
Bit Rate Type	VBR / CBR
Image Settings	ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser
Audio Compression	G711A/U
ROI	Each ROI to be configured separately
Interfaces
Network	RJ45
Video Output	No
Audio	1CH audio input; 1CH built-in MIC; 1CH audio output; 1CH built-in speaker
Storage	Built-in micro SD card slot, up to 256GB
Reset	Yes
Functions
Remote Monitoring	Web browser /TVT NVR/NVMS2.X/Mobile APP
Web Browser	IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+
Online Connection	Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, QoS
Interface Protocol	ONVIF
