MSI MAG A500N-H, 500W, 80 Plus, 120mm Fan, Protections: OVP/SCP/OPP/UVP, Dimensions: 150mmx140mmx86mm, 3Y Warranty - MAG_A500N-H
Парт.№: MAG_A500N-H
Кат.№: 154895
Кат.№: 154895
с поръчка
БЪРЗА ПОРЪЧКА (без регистрация)
Въведете Вашите данни, натиснете бутон "ПОРЪЧАЙ" и ние ще Ви се обадим!
Гаранция: 36 месеца
| Design&Features | |
| Power Device Type: | Power Supply |
| Power Device Location: | Plug-in-module |
| Form Factor: | ATX |
| Input Voltage: | AC 200-240 V |
| Input Frequency: | 50/60 Hz |
| Rated Input Current: | 6.3 A |
| Input Power Connectors Quantity: | 1 |
| Input Power Connectors Type: | IEC-320 C14 |
| Maximum Output Power: | 500 W |
| Circuit Protection: | Undervoltage Over Current Short Circuit Protection Over Power |
| Modular Power Supply: | No |
| Power Adapter and Power Supply Features: | Active PFC Low noise |
| Currents | |
| +3.3V / +5V: | 14 A (105 W) |
| +12V: | 38 A (456 W) |
| -12V: | 0.3 A (3.6 W) |
| +5VSB: | 2.5 A (12.5 W) |
| Output Connectors | |
| 24-pin Main Connector: | 1 |
| 4/8-pin +12V Power Connector: | 2 |
| 4-pin Peripheral Power Connector: | 2 |
| 4-pin Floppy Drive Connector: | 1 |
| S-ATA Connector: | 3 |
| 6/8-pin PCI Express Connector: | 1 |
| System Fans | |
| Fans Installed Quantity: | 1 |
| Fan Diameter: | 120 mm |
| Miscellaneous | |
| External Color: | Black |
| Dimensions & Weight Device | |
| Depth (mm): | 140 mm |
| Height (mm): | 86 mm |
| Width (mm): | 150 mm |
| Warranty | |
| Warranty Products Returnable: | Yes |
| Warranty Term (month): | 36 month(s) |
| Warranty Validation Criteria: | Serial Number |
| Logistic | |
| Pack Length (mm): | 338 mm |
| Pack Width (mm): | 210 mm |
| Pack Height (mm): | 157 mm |
| Pack Weight Brutto (kg): | 1.9 kg |
| Pack Weight Netto (kg): | 1.5 kg |
| Pieces in pack: | 1 |
| Box Weight Brutto (kg): | 1.9 kg |
| Packs in Box: | 1 |
| Package Type: | Box |
| EAN Code: | 4711377246583 |
